Single-Cylinder Hydraulic Cone Crusher
Welcome to the factory，A variety of models for you to choose from
The HSC single-cylinder hydraulic cone crusher is a high-performance single-cylinder hydraulic cone crusher with optimized design. It is mainly used in mining, building materials, metallurgy and other industries, and can perform medium and fine crush...
24-hour hotline
7122969
Product introduction
The HSC single-cylinder hydraulic cone crusher is a high-performance single-cylinder hydraulic cone crusher with optimized design. It is mainly used in mining, building materials, metallurgy and other industries, and can perform medium and fine crushing operations on various ores and rocks such as granite, limestone, river pebbles, basalt and iron ore.
Applications: Sand and gravel quarries, mining, concrete mixing plants, dry mortar, and other fields.
Suitable materials: granite, diabase, basalt, river pebbles, limestone, dolomite, metallic and non-metallic ores, etc.
technical parameter
|
Technical parameters |
||||||
|
model |
cavity |
Maximum feed size (mm) |
Minimum discharge opening (mm) |
Processing capacity (t/h) |
Installed power (kW) |
External dimensions (mm) |
|
HS100 |
C2 (Extra Thick) |
240 |
22 |
85-170 |
≤90 |
1550×1575×2545 |
|
|
C1 (Medium-thick) |
200 |
19 |
70-130 |
≤90 |
1550×1575×2545 |
|
|
F (fine) |
135 |
10 |
45-115 |
≤90 |
1550×1575×1965 |
|
|
F1 (Medium/Fine) |
65 |
8 |
35-80 |
≤90 |
1550×1575×1965 |
|
|
F2 (Ultra-fine) |
35 |
4 |
27-60 |
≤90 |
1550×1575×1965 |
|
HS160 |
C2 (Extra Thick) |
360 |
25 |
120-345 |
≤160 |
1875×1920×3195 |
|
|
C1 (Medium-thick) |
300 |
22 |
105-305 |
≤160 |
1875×1920×3195 |
|
|
C (coarse) |
235 |
19 |
90-275 |
≤160 |
1875×1920×3195 |
|
|
F (fine) |
185 |
13 |
66-210 |
≤160 |
1875×1920×2400 |
|
|
F1 (Medium/Fine) |
90 |
10 |
65-165 |
≤160 |
1875×1920×2400 |
|
|
F2 (Ultra-fine) |
50 |
6 |
48-105 |
≤160 |
1875×1920×2400 |
|
HS250 |
C2 (Extra Thick) |
450 |
35 |
255-605 |
≤250 |
2100×2320×4096 |
|
|
C1 (Medium-thick) |
400 |
29 |
215-515 |
≤250 |
2100×2320×4096 |
|
|
C (coarse) |
300 |
25 |
190-490 |
≤250 |
2100×2320×4096 |
|
|
F (fine) |
215 |
16 |
110-395 |
≤250 |
2100×2320×2780 |
|
|
F1 (Medium/Fine) |
110 |
13 |
115-340 |
≤250 |
2100×2320×2780 |
|
|
F2 (Ultra-fine) |
70 |
8 |
90-255 |
≤250 |
2100×2320×2780 |
|
|
C2 (Extra Thick) |
560 |
41 |
335-1050 |
≤315 |
2380×2735×4630 |
